Power Regulator Design

Price 4500 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Power Regulator Design Specification

Operating Frequency
50 Hz

Protection
Overload & Short Circuit

Control Method
Rotary Knob

Output Voltage
0-220V Adjustable

Type
Power Regulator Design

Compliance
CE Certified

Mounting Type
Panel Mount

Relative Humidity
Up to 90% RH (Non-condensing)

Display
Analog Meter

Cooling Method
Natural Air Cooled

Design
Robust & Compact

Application
Industrial Automation

Input Voltage
220V AC

Material
Metal Enclosure

Operating Temperature Range
-10C to +55C

Insulation Resistance
> 100 M

Efficiency
Above 95%

Load Capacity
Up to 10KW

Power Regulator Design Trade Information

Minimum Order Quantity
1 Number

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About Power Regulator Design

We are having more than 20 years of design experience and are specialize in all kind of Electronics and Embedded circuits designs in Microcontroller, Analog and Digital circuits, Power Systems, AHF Designs, SVG Designs, single Phase and Three Phase UPS and Inverters design, APFC Relays, SCR Switching Boards, IGBT Switching Boards, Motor Control Boards, battery-powered handheld devices, motor drivers and controllers, power systems, boards etc. Our expertise is in electronics circuit design services with a schematic design to final product. This includes selecting relevant electronic components based on the product requirements already present in the product requirements document. Additionally, we elaborate circuit design with actual electronic connections based on functional diagrams.

We do development from concept to final product.

High Efficiency and Superior Safety

Designed for rigorous industrial settings, this power regulator achieves over 95% efficiency and includes essential features like overload and short-circuit protection. Its metal enclosure and insulation resistance greater than 100 M safeguard the device and ensure operational longevity, even in high-humidity conditions.

Versatile Performance for Industrial Automation

With a wide adjustable output (0-220V) and substantial load capacity up to 10KW, this regulator meets the diverse needs of industrial automation. Precise voltage control using the rotary knob, coupled with an easy-to-read analog display, ensures optimal operation for a variety of automation equipment and panel mount environments.

FAQ's of Power Regulator Design:

Q: How does the power regulator maintain high efficiency above 95% during operation?

A: The power regulator utilizes advanced circuit design and high-quality components, complemented by natural air cooling, to minimize energy losses and achieve efficiency rates exceeding 95%, ensuring superior performance even under heavy industrial loads.

Q: What is the recommended process for installing this power regulator in an industrial panel?

A: This power regulator is designed for panel mounting. Secure installation involves fixing the regulator onto the panel with proper fasteners, connecting the input and output terminals as per the wiring guide, and ensuring reliable grounding and ventilation for optimal natural air cooling.

Q: When should I adjust the output voltage using the rotary knob?

A: You should use the rotary knob to set the desired output voltage based on the requirements of your connected load or automation system. This allows you to fine-tune the voltage from 0 to 220V AC for precise control during commissioning, routine adjustments, or when switching equipment.

Q: Where can this power regulator be effectively used?

A: This power regulator is ideal for industrial automation settings, including manufacturing lines, process control panels, and any application requiring adjustable AC voltage. Its robust, metal-enclosed design and CE certification make it suitable for use across diverse industrial environments in India.

Q: What are the benefits of using a natural air-cooled regulator over forced cooling options?

A: Natural air cooling eliminates the need for fans or active cooling systems, reducing maintenance and noise, while ensuring reliable thermal management. This enhances reliability, lowers total cost of ownership, and simplifies installation, making it preferable for many industrial applications.

Q: How does the regulator ensure safety under overload or short-circuit conditions?

A: Built-in overload and short-circuit protection mechanisms respond rapidly to abnormal conditions, disconnecting or limiting the output as needed. This protects both the device and your equipment, reducing downtime and potential damage.

Q: What is the importance of high insulation resistance (>100 M) in this regulator?

A: High insulation resistance enhances electrical safety by minimizing leakage currents and protecting internal circuits from moisture ingress and contaminant build-up, especially in high-humidity environments up to 90% RH.

Tell us about your requirement
