DC to DC Boost Converter Design

Price 4500 INR/ Number

Get a Price/Quote

MOQ : 1 Number

DC to DC Boost Converter Design Trade Information

Minimum Order Quantity
1 Number

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About DC to DC Boost Converter Design

We are having more than 20 years of design experience and are specialize in all kind of Electronics and Embedded circuits designs in Microcontroller, Analog and Digital circuits, Power Systems, AHF Designs, SVG Designs, single Phase and Three Phase UPS and Inverters design, APFC Relays, SCR Switching Boards, IGBT Switching Boards, Motor Control Boards, battery-powered handheld devices, motor drivers and controllers, power systems, boards etc. Our expertise is in electronics circuit design services with a schematic design to final product. This includes selecting relevant electronic components based on the product requirements already present in the product requirements document. Additionally, we elaborate circuit design with actual electronic connections based on functional diagrams.

We do development from concept to final product.

Adjustable Output for Versatile Applications

The DC to DC Boost Converter allows you to easily tailor output voltages between 5V and 35V DC using its multi-turn potentiometer. This flexibility makes it suitable for a wide array of power-hungry devices, from high-power motors to voltage-sensitive electronics. The compact size and passive cooling capabilities ensure it fits even in space-constrained installations.

Robust Power Conversion Efficiency

Engineered for optimal energy transfer, the boost converter delivers up to 94% efficiency, maximizing output while reducing losses. This performance means less heat is generated during operation, especially when a heatsink is attached for higher current loads. Reliable high-efficiency conversion supports demanding environments and applications.

FAQs of DC to DC Boost Converter Design:

Q: How do I adjust the output voltage of the DC to DC Boost Converter?

A: You can set the output voltage by turning the integrated multi-turn potentiometer. Rotate it slowly, using a voltmeter to monitor the output and achieve your desired voltage between 5V and 35V DC.

Q: What should I do to protect against short circuits and reverse polarity?

A: Since the module does not offer built-in short-circuit or reverse polarity protection, it is advised to install an external fuse for short-circuit safety and use a diode in series with the input to prevent potential reverse polarity damage.

Q: When is it necessary to use a heatsink with this converter?

A: A heatsink is recommended when drawing higher output currents, particularly above 3A, and is required for continuous loads up to the 6A limit to prevent overheating and maintain efficient operation.

Q: Where can I use this converter module in practical applications?

A: This boost converter is ideal for battery-powered systems, robotics, automotive electronics, and custom DIY projects where you need to step up voltage for devices requiring higher operating voltages than the supply.

Q: What is the process for installing this converter in my system?

A: Connect your DC input wires securely, making sure correct polarity is observed. Adjust the output voltage with the potentiometer, then wire the output to your target device after confirming proper voltage and installing safety components like a fuse and input diode.

Q: What are the benefits of using a non-isolated step-up converter module?

A: Non-isolated converters deliver compact size, higher efficiency, and direct ground referencing, making installation straightforward while reliably boosting voltage with minimal thermal loss when supplemented with passive or additional heatsink cooling.
